PVC Fittings Injection Molding Machine

Categories : Special custom series

Introduction to PVC Fittings Injection Molding MachineThe PVC fittings injection molding machine is a highly efficient injection molding equipment specifically designed for the production of high-quality PVC fittings.It features the following highlights:High-Speed Production• Fast

Technical parameter

YH Series Servo Energy-Saving Injection Molding Machines
YH-308
International Size Rating		1560
Injection Unit
Screw specification		A	B		C	D
Screw diameter	mm	55	60		65	/
Screw ratio	L/D	21.8	20		18.4	/
Theoretical injection capacity	cm³	713	848		995	/
Injection weight	g	649	772		906	/
Injection rate	g/s	220	262		307	/
Injection pressure	Mpa	219	184		156	/
Screw rotation speed	r/min	0-200
Clamping Unit				Auxiliary machine specifications
Clamping force	KN	3080		Dryer		100kg
Mold opening stroke	mm	560		Feeder		800g
Space between tie bars	mm	625×575		Air switch specification		A
Max.Mold Height	mm	600		Power cord specification		mm²
Min.Mold Height	mm	200		Mold positioning ring specification (mm)		Ø100
Ejector Stroke	mm	160		Nozzle aperture (mm)		Ø4.5
Ejector Force	KN	70		Nozzle spherical R angle		SR
Others				Mold clamping screw specification		M20
Oil pump motor power	KW	36.5		Template outline dimension (mm)
Heater power	KW	17.2		Foundation bearing requirement
Machine dimension	M	6.7×1.8×2.0		Oil cooler water flow requirement (L/min)
Machine weight	T	9.2		Cooler inlet and outlet pipe interface
Hopper capacity	L	50		Minimum mold size (length × width) (mm)
Oil Tank Capacity	L	390
Instructions: 1. Theoretical injection volume = cross-sectional area of the injection molding machine's barrel × injection stroke 2. Actual injection volume = theoretical injection volume × 0.91 (calculated based on GPPS)

Product Description

Introduction to PVC Fittings Injection Molding Machine

The PVC fittings injection molding machine is a highly efficient injection molding equipment specifically designed for the production of high-quality PVC fittings.It features the following highlights:

High-Speed Production

• Fast Molding Cycle：Equipped with advanced injection molding technology,it offers a short molding cycle and fast injection speed,significantly improving production efficiency to meet large-scale production demands.

• Synchronized Functionality：It features a synchronized function of mold opening and material storage,optimizing the production process and shortening the production cycle to further enhance production speed.

Energy-Saving and Electricity-Conserving

• Efficient Energy System：Adopting advanced energy-saving technologies,it significantly reduces energy consumption compared to traditional injection molding machines,saving a considerable amount of electricity and reducing production costs.

• Smart Energy Management：The intelligent energy management system automatically adjusts power according to production needs,further reducing energy consumption and saving operational costs for businesses.

Precise Control

• High-Precision Control System：It is equipped with a high-precision control system that can accurately control key parameters such as temperature,pressure,and speed during the injection molding process,ensuring the stability and consistency of the quality of PVC fittings.

• User-Friendly Interface：The simple and intuitive operation interface allows users to easily monitor and adjust production parameters,ensuring the efficiency and stability of the production process.

Stable and Reliable

• High-Quality Components：It features high-quality T-slot templates and linear guides,ensuring the stability and precision of machine operation,reducing vibration and wear,and extending the service life of the equipment.

• T-Slot Template：Facilitates quick mold installation and adjustment,improving production efficiency and reducing machine downtime.

• Linear Guides：Provide precise motion control,ensuring smooth and accurate mold opening and closing,further enhancing product quality.

Efficient Design

• Quick Mold Change：The T-slot template design supports rapid mold change,significantly reducing machine downtime and improving production efficiency.

• Precise Motion Control：Linear guides ensure smooth and precise mold opening and closing,further enhancing production efficiency and product quality.

The PVC fittings injection molding machine,with its high-speed,energy-saving,precise,and stable performance,is an ideal choice in the field of PVC fittings production.It can help enterprises stand out in fierce market competition and achieve efficient and energy-saving production goals.
